HZS75 Wet Mix Stationary Concrete Batching Plant / Concrete Mixing Plant
HZS75 Wet Mix Stationary Concrete Batching Plant / Concrete Mixing Plant eatured with compact structure and land saving, with patent technology, ZHENHENG concrete batching plant has 30%-45% higher efficiency than the average level.
HZS75 Wet Mix Stationary Concrete Batching Plant / Concrete Mixing Plant is mainly composed of 5 major systems, such as the mixing host, the material weighing system, the material conveying system, the material storage system and the control system, and other auxiliary facilities.
Main Parameter Information of HZS75 Wet Mix Stationary Concrete Batching Plant / Concrete Mixing Plant
| Model | HZS75 | | Productivity | 75 m³/h | | Type of Mixer | JS1500 | | Mixing Volume(L) | 1500 L | | Feeding Way | Skip Hopper | | (Bucket Type) | | Discharge Height | 3.8 m | | Aggregate Bins | 4 | | Aggregate Weighing Range | 1000-2000 kg | | Cement Weighing Range | 800 kg | | Max. Aggregate Size | 80/60 mm | | Total Power | 77 kw | | Total Weight | 35 T | |
1) Mixing System of HZS75 Wet Mix Stationary Concrete Batching Plant / Concrete Mixing Plant: the mixer is JS1500 twin shaft forced type which has high mixing evenness for concrete, short mixing time, long life span for wearing parts, easy operation and maintenance advantages. 3.8m discharging height. Adjustable hydraulic discharging door angle. High Wear-Resistant Chromium-Manganese Alloys Plates and Blades. Perfect shaft end sealing system effectively prevents leakage and guarantees the continuous long running of the whole mixing system.
2) Batching System of HZS75 Wet Mix Stationary Concrete Batching Plant / Concrete Mixing Plant: using PLB2400 batching machine. The batching aggregates can be 2-4 types. 12m3 Basic Storage Bins Volume,2400L Weighing Bins Volume, Full Capacity, 3kw Motor.
3) Feeding System of HZS75 Wet Mix Stationary Concrete Batching Plant / Concrete Mixing Plant: using hopper feeder, and our anti-block patents technology ensures forever non-block.
4) Weighing system of HZS75 Wet Mix Stationary Concrete Batching Plant / Concrete Mixing Plant: with buffering device, auto compensation function and very high weighing accuracy. The sensors for the weighing system are of China Famous Brand with assured high weighing accuracy and stability.
5) Control System of HZS75 Wet Mix Stationary Concrete Batching Plant / Concrete Mixing Plant: international advanced full auto SIMENS PLC+PC control model. It can also use PLC semi-auto control system or manual control system to hugely save cost.
FAQ of HZS75 Wet Mix Stationary Concrete Batching Plant / Concrete Mixing Plant
Q: What’s your after-sale service?
A: 12 months warranty for main parts since departure.
On-site installation, debugging, workers training. Make sure that your workers operate properly and know daily maintenance well.
Q: What’s your delivery time?
A: Generally it is 7-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
Q. How long do you warranty your concrete batching plant?
A: We shall guarantee that the commodity for 1 year, excluding the wearing parts, and we will offer our customers the wearing parts all the time with favorable price.
Q. How can we install the plant?
A: Our engineer will make installation drawing before we send the machine, and our engineer will go oversea to guide and train the installation after everything is already set in customer's construction site.
Product Tags:
|
|
HZS75 Wet Mix Stationary Concrete Batching Plant / Concrete Mixing Plant Images
|
